HyPerformance HPR400XD
The HyPerformance® HPR400XD® plasma system has been designed and built for maximum performance and productivity in X-Y, bevel, and robotic cutting operations. The versatile 400-amp rated system combines fast cutting speeds, rapid process cycling, quick changeovers and high reliability, and delivers the ultimate in HyPerformance mild steel cutting, plus aluminum capability and unmatched stainless steel cut quality.
System information
Benefits
Superior cut quality and consistency
- HyPerformance plasma cuts fine-feature parts with superior quality and consistency
- HyDefinition® technology aligns and focuses the plasma arc for more powerful precision cutting up to 80 mm (3.2")
- New HDi™ technology delivers HyDefinition cut quality on thin stainless steel, with extremely sharp top edge quality, shiny surface finish, and superior angularity with reduced angle variation
- Patented True Hole™ technology (auto gas systems only) produces hole quality that is significantly better than anything previously achievable with plasma
Minimized operating cost
- LongLife® technology significantly increases consumable life and enables consistent HyDefinition cut quality
- Faster cut speeds let you produce more parts per hour; higher quality cutting virtually eliminates the cost of secondary operations
- Patented PowerPierce® technology lets you pierce thicker than ever before and replace slower-cutting oxyfuel technology
“Do anything” versatility
- Cuts, bevels, and marks carbon steel, stainless steel, aluminum, and other metals with HyDefinition precision
- Modular system design allows easy power supply upgrades to increase system capabilities when requirements change
Industry-leading reliability
- Robust, simple system architecture with 50% fewer parts than most competitive systems
- Best-in-class manufacturing and extensive testing ensure that every Hypertherm system meets the highest quality standards
Specifications
| General | |
|---|---|
| Maximum OCV (U0) | 360 VDC |
| Maximum output current (I2) | 400 Amps |
| Output voltage (U2) | 50 – 200 VDC |
| Duty cycle rating (X) | 100% @ 80 kw, 40° C (104° F) |
| Ambient temperature/Duty cycle | Power supplies will operate between -10° C and +40° C (+14° and 104° F) |
| Power factor (cosφ) | 0.98 @ 400 ADC output |
| Cooling | Forced air (Class F) |
| Insulation | Class H |
| Mild steel cut capacity | Dross free Production pierce Maximum cutting capacity |
38 mm (1-1/2")
50 mm (2") 80 mm (3.2") |
| Stainless steel cut capacity | Production pierce Maximum pierce** Severance |
45 mm (1-3/4")
75 mm (3") 80 mm (3.2") |
| Aluminum cut capacity | Production pierce Severance |
45 mm (1-3/4")
80 mm (3.2") |
| Speed (Mild steel) |
Book specification at highest output current |
12 mm (1/2")
4430 mm/m (170 ipm) |
| Cut angle | ISO 9013 range* |
2-4
|
| Weldability | Ready to weld | |
| Process gases by material (Plasma/shield) |
Mild steel Stainless steel Aluminum |
02/Air, 02/02 |
| Process amps (Cutting) |
Not all processes available for all materials |
30-400 |
* ISO 9013 is a standard that defines cut quality of thermally cut parts. The lower the range (range 1 is the lowest), the smaller the angle on the cut face. Cut angle in range 4 is better than in range 5.
** Maximum pierce requires usee of an autogas console and controlled motion process. See technical documentation for details.
Buying information
Visit our where to buy page to find a potential partner, or contact Hypertherm directly if you need further assistance.
Resources
Manuals and documents
HPR cartridge - simplify your cutting process
PDF (1.22MB)
Maintenance
Learn how the HPR cartridge makes it simple
Delivering longer life and extended cut quality, the single-piece HPR cartridge for HPRXD systems replaces five traditional consumables with just one – for simplified ordering, faster change-outs, and fewer errors.
HPR cartridge
HPR cartridge consumablesNew!
| Mild steel process | Retaining cap | Cartridge | Water tube | Torch body |
|---|---|---|---|---|
| 80 A (standard cutting)* | 420708 | 420803 | 420728 | 420729 |
| 130 A (standard cutting)* | 420708 | 420705 | 420728 | 420729 |
| 260 A (standard cutting / bevel cutting)* | 420708 | 420715 | 420728 | 420729 |
* HPR cartridge require a new torch body, water tube, and retaining cap. The HPR cartridge torch body connects directly to a standard HPRXD receptacle (part number 220705).
HPR cartridge kitsNew!
| Type | Kit p/n | Includes p/n | Description | Quantity |
| Torch starter kit | 528101 | 420729 | Torch body | 1 |
| 420728 | Water tube | 1 | ||
| 420708 | Retaining cap | 1 | ||
| 528107 | Kit: O-ring cartridge torch | 1 | ||
| Cartridge 3-pk kits |
528102 | 420803 | Kit: Cartridge, 80 A | 3 |
| 528103 |
420705 |
Kit: Cartridge, 130 A | 3 | |
| 528104 | 420715 | Kit: Cartridge, 260 A | 3 | |
| 528105** | 420803, 420705, 420715 | Kit: Cartridge, multi-amps | 3 |
** Note: 528105 cartridge multi-amps kit contains (1) of each amperage (80 A, 130 A, and 260 A).
HPR400XD standard consumables
HPR400XD torch
Mild steel
400 amp consumables - mild steel
| Amperage | Shield cap | Shield | Nozzle retaining cap | Nozzle | Swirl ring | Electrode | SilverPlus electrode | Water tube |
|---|---|---|---|---|---|---|---|---|
| 30 A | 220747 | 220194 | 220754 | 220193 | 220180 | 220192 | ______ | 220340 |
| 50 A | 220747 | 220555 | 220754 | 220554 | 220553 | 220552 | ______ | 220340 |
| 80 A | 220747 | 220189 | 220756 | 220188 | 220179 | 220187 | 420566 | 220340 |
| 130 A | 220747 | 220183 | 220756 | 220182 | 220179 | 220181 | 220665 | 220340 |
| 200 A | 220637 | 220761 | 220757 | 220354 | 220353 | 220352 | 220666 | 220340 |
| 260 A | 220637 | 220764 | 220760 | 220439 | 220436 | 220435 | 220668 | 220340 |
| 400 A | 220637 | 220636 | 220635 | 220632 | 220631 | 220629 | 420530 | 220571 |
| 80 A bevel | 220637 | 220742 | 220845 | 220806 | 220179 | 220802 | ______ | 220700 |
| 130 A bevel | 220637 | 220742 | 220740 | 220646 | 220179 | 220649 | ______ | 220700 |
| 200 A bevel | 220637 | 220658 | 220845 | 220659 | 220353 | 220662 | ______ | 220700 |
| 260 A bevel | 220637 | 220741 | 220740 | 220542 | 220436 | 220541 | ______ | 220571 |
| * 260 A bevel | 220637 | 220897 | 220896 | 220898 | 220436 | 220899 | ______ | 220571 |
| 400 A bevel | 220637 | 220636 | 220635 | 220632 | 220631 | 220629 | ______ | 220571 |
* Recommended for use if you have excessive slag, or the torch is misfiring, when using standard consumables.
Stainless steel
800 amp - stainless steel - above 4″ thick
| Amperage | Shield cap | Shield | Nozzle retaining cap | Nozzle | Swirl ring | Electrode | Water tube |
|---|---|---|---|---|---|---|---|
| 45 A | 220747 | 220202 | 220755 | 220201 | 220180 | 220308 | 220340 |
| 60 A HDi | 220747 | 220815 | 220814 | 220847 | 220180 | 220339 | 220340 |
| 80 A | 220747 | 220338 | 220755 | 220337 | 220179 | 220339 | 220340 |
| 130 A | 220747 | 220198 | 220755 (H35) 220756 (N2) |
220197 | 220179 | 220307 | 220340 |
| 200 A | 220637 | 220762 | 220758 | 220343 | 220342 | 220307 | 220340 |
| 260 A | 220637 | 220763 | 220758 | 220406 | 220405 | 220307 | 220340 |
| 400 A | 220637 | 220707 | 220712 | 220708 | 220405 | 220709 | 220571 |
| 130 A bevel | 220637 | 220738 | 220739 | 220656 | 220179 | 220606 | 220571 |
| 260 A bevel | 220637 | 220738 | 220739 | 220607 | 220405 | 220606 | 220571 |
| 400 A bevel | 220637 | 220707 | 220712 | 220708 | 220405 | 220709 | 220571 |
Aluminum
400 amp - aluminum consumables - above 4″ thick
| Amperage | Shield cap | Shield | Nozzle retaining cap | Nozzle | Swirl ring | Electrode | Water tube |
|---|---|---|---|---|---|---|---|
| 45 A | 220747 | 220202 | 220756 | 220201 | 220180 | 220308 | 220340 |
| 130 A | 220747 | 220198 | 220755 (H35) 220756 (Air) |
220197 | 220179 | 220307 (H35) 220181 (Air) |
220340 |
| 200 A | 220637 | 220762 | 220759 | 220346 | 220342 | 220307 | 220340 |
| 260 A | 220637 | 220763 | 220758 | 220406 | 220405 | 220307 | 220340 |
| 400 A | 220637 | 220707 | 220712 | 220708 | 220405 | 220709 | 220571 |
HPR400XD standard consumable starter kits
Designed especially for your HPR400XD system, the Hypertherm consumable kit contains all the necessary consumables and accessories you need to get up-and-cutting. Customers can choose either mild or stainless steel/aluminum consumable starter kits.
| Kit type (MS) | HPR400XD mild steel starter kit (400 A and below) |
|---|---|
| Kit part number | 228367 |
| Description | Kit contains all the necessary consumables and accessories for mild steel cutting at 400 A and below |
| Kit type (AL/SS) | HPR400XD aluminum and stainless steel starter kit (400 A and below) |
|---|---|
| Kit part number | 228368 |
| Description | Kit contains all the necessary consumables and accessories for aluminum and stainless steel cutting at 400 A and below |
